Upgrade Material
The Kailh Deep Sea Silent Pro Box Switch is the descendant of the original Kailh Deep Sea Silent Box Switch. This new switch features a blue transparent PC cover, a dark blue nylon base, and a transparent prolong stem to give the feeling of the deep sea. It looks like art on a keyboard and provides a more stable and quiet feel.
Factory Pre-lubed
These switches are pre-lubed before leaving the factory to reduce the spring from scratching and hitches. By doing so, it also reduces the spring rebounding sound a bit to allow for quieter feedback when triggered.
Extended Spring
The extended spring has a more uniform pressure force and faster rebound than the ordinary spring.
Linear/ Tactile
It is available in both tactile and linear. Each will offer you a different typing experience.
Linear/ Tactile
The extended spring has a more uniform pressure force and stronger rebound than the ordinary spring.
Better Backlight
The pro switches have better backlight transmittance than the original switches because of their transparent cover and tapered light guide to allow more light to shine through to the typist or gamer.
Product Structure
Technical Data
Islet Switch
| Type | Linear |
|---|---|
| Operation Force | 45±10 gf |
| Pre-travel | 1.8±0.4 mm |
| Return Force | ≥15 gf |
| Tactile Force | - |
| Total Travel | 3.6±0.4 mm |
| Sound Level | Silent |
| Operation Life | Up to 100M cycles |
| Suitable For | Gaming/office |
Whale Switch
| Type | Tactile |
|---|---|
| Operation Force | 40±10 gf |
| Pre-travel | 2.0±0.4 mm |
| Return Force | ≥15 gf |
| Tactile Force | 60±10 gf |
| Total Travel | 3.6±0.4 mm |
| Sound Level | Silent |
| Operation Life | Up to 100M cycles |
| Suitable For | Midway gaming/office |
Product Spec
| Product Name | Kailh Deep Sea Silent Pro Box Switch |
|---|---|
| Stem | Clear plastic |
| Top Housing | PC |
| Bottom Housing | Nylon |
| Contact | Composite gold |
| Spring | Spring steel |
| Protecting Cover | PC |
| Slider | POM |
| Light Guide Post | PC |
| Pins | 3-Pin |
| Factory Pre-lubed | Yes |
| SMD LED Support | Yes |
