Tactile Typing Feel
The Kailh Crystal Royal Box Switch is a tactile switch that features a crisp bump. It has an operation force of 45 grams, and a tactile force of 75 grams, and provides noticeable tactile feedback. It is an ideal option for those who prefer a tactile typing experience.
Gold Plated Spring
This switch adopts a gold-plated spring to enhance its oxidation resistance and anti-vulcanization performance.
Double Dustproof & Waterproof Structure
By equipping this switch with a dust wall design and box structure, these Box switches have IP56 degrees of protection and prevent dust and water from causing corrosion.
Excellent Backlight Effect
This switch adopts a transparent housing to increase light permeability and provides prime lighting to the typist or gamer.
Excellent Backlight Effect
This switch adopts a transparent housing to increase light permeability and provides prime lighting to the typist or gamer.
5-Pin Scheme
The 5-Pin structure provides stability and less wobbliness for this switch when pressed.
Product Structure
Technical Data
Crystal Royal Box Switch
| Type | Tactile |
|---|---|
| Operation Force | 45±15 gf |
| Pre-travel | 1.8±0.4 mm |
| Return Force | ≥15 gf |
| Tactile Force | 75±10 gf |
| Total Travel | 3.6±0.3 mm |
| Sound Level | Medium |
| Operation Life | Up to 80M cycles |
| Suitable For | Midway Gaming/office |
Product Spec
| Product Name | Kailh Crystal Royal Box Switch |
|---|---|
| Stem | POM |
| Top Housing | PC |
| Bottom Housing | PC |
| Contact | Composite gold |
| Spring | Spring steel |
| Protecting Cover | Nylon PA66 |
| Slider | POM |
| Pins | 5-Pin |
| Factory Pre-lubed | No |
| SMD LED Support | Yes |
